This surface mountable (no mounting panel required) circuit breaker combines switching and circuit breaker functions into one unit.

• Ignition protected – Safe for installation aboard gasoline powered boats
• Meets SAE J1171 external ignition protection requirements
• Weather Resistant
• Combines switching and circuit breaker function into one unit
• “Trip Free” – cannot be held closed after trip

Specifications

• Case Material Phenolic
• Circuit Breaker Class Type III – Switchable/Manual Reset – Trip Free
• Weight Lb (Kg) 0.30 (0.14)
• Interrupt Rating 3,000 Amperes DC
• Terminal Stud Torque 70 in-lb
• Maximum Voltage Rating 42 Volts DC
• Circuit Breaker Type Thermally responsive bi-metal blade
• Operating Temperature Range -25C to +82C
