Designed for exposed mounting applications

• Illuminated 15A circuit breakers provide switching, ON indication and overcurrent protection
• Industry-standard sizes and mounting allow these panels to be easily retroftted in an existing application
• Polycarbonate/ABS panel surface is UV-stabilized, ?ame retardant, and will not corrode
• Silicon breaker boots and gasket protects against water ingress
• Low profle makes it easy to install in tight spaces
• Fast-on circuit breaker connectors make it quick to wire
• Two-wire connection for powering all panels is simple and requires #10 ring terminals. Terminals screw to bus bars for secure connections
• Set of 15 square format circuit labels are included, and are easy to replace. Additional standard or custom labels are available through Blue Sea Systems

Specifications Color Gray Positions 6 Nominal Voltage 12V DC Maximum Amperage 45A Terminal Type 1/4″ Male quick connect Hardware Stainless Steel #6 x 5/8″ mounting screws Ring Terminal Size M5 (#10) Height 6.625in (168.28 mm) Width 4.625in (117.48 mm) Depth 1.75in (44.45 mm)
