Series S constitutes a product family of four straight and four V-shaped interceptors. This first-ever modular design made for mass production makes the interceptors durable, affordable and perfectly adapted to any planing or semi-planing boat between 6 m and 18 m (20-60ft).

All components have been meticulously engineered to withstand impact and avoid water ingress, minimizing the risk of costly maintenance and downtime. Interceptor or blade actuation takes place by way of a calibration-free submersible electric servo within the interceptor unit. Its natural water cooling provides excellent working conditions for the brushless DC servo motor, which runs on 12-32 volts. The blade stroke takes 1.5 seconds, outperforming conventional trim tabs by at least a factor of 5.

Installation is made easy with an integral mounting plate and the option of a concealed or above waterline, self-sealing, thru-hull cable fitting. Each interceptor comes with the thru hull cable fitting, cable covers and a practical drill template.

Features:

• True outboard mount, modular design and fast actuation
• Integrated mounting plate and no corrosive materials
• Thru-hull fitting options either above waterline or concealed behind interceptor
• Submersible servo units are brushless 12-24V DC servo motor, high-precision positioning, calibration free, durable and accessible

Name Description Certifications & Compliance CE, FCC Max Boat Speed 60 knots Blade Stroke 1.2″ (30mm) Blade Rate 0.8 in/s (20 mm/s) Thru-Hull Cable Fitting Concealed or above waterline Servo Actuator SU-S Cable Material PUR Connector M12 5-pin circular Connector Diameter 0.57″ (14.5 mm) Manufacturers Part No 300-2W2011232ZW2011232 Cable Length 10′ (3 m), extendable up to 20′ (6 m) Voltage 12-32VDC Power Consumption 25W max Ingress Protection IP68, 16′ (5 m) Operating Temperature +32 to +104F (0 to +40C) Storage Temperature -40 to +194F (-40 to +90C) Approximate Ship Weight (lbs) 8
